SIMULATION TOOLS

Cadence Academic Bundle
Conformal Low Power GXL	Virtuoso AMS Designer Environment	Innovus Mixed Signal Option
Genus Low Power Option	Virtuoso Schematic Editor	Innovus Hierarchical Design Option
Genus Physical Option	Virtuoso ADE Assembler	Innovus Implementation System
Genus Synthesis Solution	Virtuoso Layout Suite GXL	JasperGold Formal Verification Platform
Cadence SKILL Development Environment	Voltus-Fi Custom Power Integrity Solution XL	Modus DFT Option
Virtuoso- Schematic Editor Verilog Interface	Allegro Venture PCB Designer	Modus ATPG Distributed Base
Cadence Pegasus 16nm Node	Cadence Quantus Extraction XL	Tempus Timing Signoff Solution XL
Cadence Pegasus Design Rule Check	Sigrity Advanced SI II	Voltus IC Power Integrity Solution XL
Cadence Pegasus Layout vs. Schematic Check	Spectre RelXpert Reliability Simulator	Tempus Timing Signoff Solution ECO
Cadence Pegasus DFM Fill	Spectre AMS Designer	Manager Project Server
Keysight Advanced Design System (ADS)
TSMC Process Development Kits (Pdks) integrated witrh licencesd Cadence Tools
180nm CMOS	130nm CMOS	65nmCMOS
28nm CMOS	180nm BCD
Have access for techologies available through CMP & AMS
Have well establishedecosystem of open source Analog, Digital & Mixed Signal ICD Tool Suite

LAB EQUIPMENTS

Covers a frequency range of 1 MHz to 8 GHz with Extended K⁺ ports.
Offers a frequency resolution of 1 Hz, ensuring accuracy within 1.0 ppm at the time of calibration.
Stability maintained within ± 1.0 ppm across temperatures ranging from -10 °C to +55 °C.
Provides a sweep speed of 130 μs per data point, typical.

Covers a frequency range of 100 kHz to 3 GHz.
Demonstrates a DANL of -156 dBm/Hz, normalized to 1 Hz.
Best-in-class dynamic range with +18 dBm TOI.
Maintains overall amplitude accuracy within ±0.5 dB.
Brightest, highest resolution display in its class (21 cm XGA, 1024 x 768) & 1 dB electronic step input attenuator

Boasts a bandwidth of 1 GHz & Provides vertical resolution of 8 bits
Features 2 analog channels and 16 time-correlated digital channels.
Offers a sample rate of 4 GSa/s and a record length of 2 Mpts.
Ensures complete connectivity through USB, LAN, GPIB, XGA display out, and LXI Class C compliance as standard.
Supports powerful application suites such as I2C, SPI, and USB triggering and decode, as well as CAN, LIN, and FlexRay triggering and decode, Rapid Xilinx, and Altera FPGA debug.
